MINI Board
AD-C05
RK3566 Quad-core 64-bit Cortex-A55
4K HD Out
WIFI & Bluetooth Support
4G PCIE function optional
RK3566 / RK3288 / RK3399 / RK3566 / RKPX30 / RK3128 /etc. optional
CPU | Rockchip RK3566 Quad-core 64-bit Cortex-A55 GPU Mali-G52 |
RAM | LPDDR3 2G/4G Optional |
ROM | EMMC 8GB/16G/32G/64G etc. optional |
Network | With RJ45 interface subboard,Support 10/100M Ethernet |
External 4G PCIE interface | |
With WIFI & BT module , supporting Wi-Fi 802.11b/g/n protocol. Support BT4.0 | |
Real Time Clock | Built-in real-time clock powered battery |
Interfaces | 5*USB2.0,USB3.0, 3*UART,LVDS, EDP, MIC,POE,GPIO,SD card Slot, HDMI OUT,Ethernet,Earphone,Type-C,2*Power-in, |
Video | Support 4K 60fps H.265/H.264/VP9 video decoding; support 1080P 100fps H.265/H.264 video encoding; support 8M ISP |
Other solutions | RK3566 / RK3288 / RK3399 / RK3566 / RKPX30 / RK3128 /etc. |
